Armstrong Astro 230CI 3-Speed Cast Iron Circulator, 0-20 GPM Flow for Closed Loop Hydronic Heating Systems

Sku:
ASTRO-110223305
In Stock, Ships Next Business Day
$125.00

A hydronic heating system is a closed-loop system, meaning the water stays in the piping. Typically the base of a hydronic heating system is a heating system operated with a boiler. Radiators, baseboard heating and even some radiant floor heating systems tend to be hydronic / closed-loop systems. Most of these types of systems use water, although some can use other liquids. Like most heating systems, it is controlled by a thermostat to turn it on and off, and control the temperature. The circulator helps move the hot water through your system, ensuring the hot water reaches the furthest point of your system. The pump includes an impeller motor that moves the hot water from your boiler through the pipes, while at the same time drawing cold water into the boiler to start the heating process. If you notice loud or strange noises or leaking, it is a good sign that your circulator needs replacing. A leaky pump might cause a drop in water pressure in your home, resulting in less heat reaching all areas of your home.

The 230CI 3-Speed Cast Iron Circulator is the most versatile circulator for home owners. It offers a 0 - 20 GPM flow rate. It will operate in conditions where the maximum ambient temperature is 104°F (40°C) and a maximum water / liquid temperature of 230°F (110°C) with a max. pressure of 150 psi. It offers 3 speeds and is a maintenance free circulator. It is for use with Water Only and Water/ Glycol Mixture (Ethylene, Propylene only) hydronic heating systems.

Designed for residential hydronic heating systems, the Armstrong Astro 2 230CI 3-Speed Cast Iron Circulator circulates the water in your closed-loop system. The 230CI 3-Speed circulator offers contractors a wide variety of replacement possibilities with a single circulator, reducing on-hand inventory. The 3 speeds give you a wide array of setting depending on the needs of the system. The Astro 2 230CI can be used to replace several brands of circulators. For a comparison of popular circulators, please see the Cross Reference Chart under Manuals and Guides.

FREE SHIPPING ON ALL ORDERS!
Armstrong Astro 230CI 3-Speed Cast Iron Circulator, 0-20 GPM Flow for Closed Loop Hydronic Heating Systems
  • Armstrong Astro 230CI 3-Speed Cast Iron Circulator, 0-20 GPM Flow for Closed Loop Hydronic Heating Systems
  • Armstrong Astro 230CI 3-Speed Cast Iron Circulator, 0-20 GPM Flow for Closed Loop Hydronic Heating Systems

Product Overview

A hydronic heating system is a closed-loop system, meaning the water stays in the piping. Typically the base of a hydronic heating system is a heating system operated with a boiler. Radiators, baseboard heating and even some radiant floor heating systems tend to be hydronic / closed-loop systems. Most of these types of systems use water, although some can use other liquids. Like most heating systems, it is controlled by a thermostat to turn it on and off, and control the temperature. The circulator helps move the hot water through your system, ensuring the hot water reaches the furthest point of your system. The pump includes an impeller motor that moves the hot water from your boiler through the pipes, while at the same time drawing cold water into the boiler to start the heating process. If you notice loud or strange noises or leaking, it is a good sign that your circulator needs replacing. A leaky pump might cause a drop in water pressure in your home, resulting in less heat reaching all areas of your home.

The 230CI 3-Speed Cast Iron Circulator is the most versatile circulator for home owners. It offers a 0 - 20 GPM flow rate. It will operate in conditions where the maximum ambient temperature is 104°F (40°C) and a maximum water / liquid temperature of 230°F (110°C) with a max. pressure of 150 psi. It offers 3 speeds and is a maintenance free circulator. It is for use with Water Only and Water/ Glycol Mixture (Ethylene, Propylene only) hydronic heating systems.

Designed for residential hydronic heating systems, the Armstrong Astro 2 230CI 3-Speed Cast Iron Circulator circulates the water in your closed-loop system. The 230CI 3-Speed circulator offers contractors a wide variety of replacement possibilities with a single circulator, reducing on-hand inventory. The 3 speeds give you a wide array of setting depending on the needs of the system. The Astro 2 230CI can be used to replace several brands of circulators. For a comparison of popular circulators, please see the Cross Reference Chart under Manuals and Guides.

Tech Specs

Max. Flow Rate (GPM):
20
Flow Range (GPM):
0 - 20
Max. Fluid Temp.:
230°F / 110°C
Speeds:
3
Max. Head (ft.):
18
Head Range (ft.):
0 - 18
Connection:
Flange - (2) 1/2" bolt holes
Voltage:
115
California residents see Prop 65 WARNINGS

Warning WARNING!

Warning: Cancer and Reproductive Harm - www.p65warnings.ca.gov

Product Warranty

Armstrong warrants Armstrong-manufactured Circulators to be free from defects in material and workmanship under normal use and service for 30 months from date of manufacture.
