Superior TF18PV 18" Vent Free Triple Flame Burner with Variable Flame Valve - Liquid Propane

Sku:
SUPERIOR-TF18PV
Usually Leaves Warehouse in 2 - 3 Business Days
$1,219.00
Burners are certified to work with SPECIFIC Log Sets only. While there may be several allowable Log Sets for a specific burner, they are NOT universal. Using a burner with a non-compatible log set can lead to Fire, Carbon Monoxide Poisoning and Property Damage.
The Triple Flame Vent Free Burner requires no outside venting so there is no heat loss - you get 99% heat efficiency. The Tri-Flame Burner offers a truly unique look to any gas fireplace with its additional row of flames that flicker and dance from behind the logs along with its glowing ember bed. The real-look wood-burning grate allows for a deep and realistic flame pattern while coals and embers glow from below. Yellow flames rise from the rear and center logs. You get the beauty of a wood burning fireplace, without the mess or the hassle. The TF18PV Triple Flame Burner includes a variable flame valve with on/off switch. Optional on/off accessories include a remote (RCKIT4001), and a wall-mount thermostat switch (GWMT1).

The TF18PV 18" Triple Flame Burner with Variable Flame Valve is for use with Liquid Propane and includes embers and a Proflame remote. The remote features LED Digital Display and offers both manual and thermastatic modes. Additionally, it has on/off and 5 flame heights. It can be used with 18" Wild Timber and Rugged Stack Log Sets only. The variable flame burner is rated for 24,000 - 30,000 BTUs. Minimum fireplace dimensions are:
  • Front Width: 28"
  • Height: 20"
  • Rear Width: 20"
  • Depth: 14"

For the Liquid Propane Tri-Flame Vent Free Burner with Variable Flame Valve, the Manifold Pressure is 7.9" WC and the Min. / Max. Gas Pressure is 11" WC / 14" WC. This burner is also available in Natural Gas (TF18NV).

A licensed gas technician is required for installation of this product. Please check your local regulations as some areas may require inspection after installation of gas products. It is highly recommended that you use your own gas technician or gas provider for any repairs.

Vent-Free Products Cannot Be Shipped To The State Of California.
State and local codes in some areas prohibit the use of vent free products.
PLEASE CHECK YOUR LOCAL BUILDING CODES BEFORE ORDERING OR INSTALLING A VENT FREE PRODUCT.
FREE SHIPPING ON ALL ORDERS!
Superior TF18PV 18" Vent Free Triple Flame Burner with Variable Flame Valve - Liquid Propane

Product Overview

Burners are certified to work with SPECIFIC Log Sets only. While there may be several allowable Log Sets for a specific burner, they are NOT universal. Using a burner with a non-compatible log set can lead to Fire, Carbon Monoxide Poisoning and Property Damage.
The Triple Flame Vent Free Burner requires no outside venting so there is no heat loss - you get 99% heat efficiency. The Tri-Flame Burner offers a truly unique look to any gas fireplace with its additional row of flames that flicker and dance from behind the logs along with its glowing ember bed. The real-look wood-burning grate allows for a deep and realistic flame pattern while coals and embers glow from below. Yellow flames rise from the rear and center logs. You get the beauty of a wood burning fireplace, without the mess or the hassle. The TF18PV Triple Flame Burner includes a variable flame valve with on/off switch. Optional on/off accessories include a remote (RCKIT4001), and a wall-mount thermostat switch (GWMT1).

The TF18PV 18" Triple Flame Burner with Variable Flame Valve is for use with Liquid Propane and includes embers and a Proflame remote. The remote features LED Digital Display and offers both manual and thermastatic modes. Additionally, it has on/off and 5 flame heights. It can be used with 18" Wild Timber and Rugged Stack Log Sets only. The variable flame burner is rated for 24,000 - 30,000 BTUs. Minimum fireplace dimensions are:
  • Front Width: 28"
  • Height: 20"
  • Rear Width: 20"
  • Depth: 14"

For the Liquid Propane Tri-Flame Vent Free Burner with Variable Flame Valve, the Manifold Pressure is 7.9" WC and the Min. / Max. Gas Pressure is 11" WC / 14" WC. This burner is also available in Natural Gas (TF18NV).

A licensed gas technician is required for installation of this product. Please check your local regulations as some areas may require inspection after installation of gas products. It is highly recommended that you use your own gas technician or gas provider for any repairs.

Vent-Free Products Cannot Be Shipped To The State Of California.
State and local codes in some areas prohibit the use of vent free products.
PLEASE CHECK YOUR LOCAL BUILDING CODES BEFORE ORDERING OR INSTALLING A VENT FREE PRODUCT.

Tech Specs

General Features

Fireplace Style:
Single Sided
Location of Use:
Indoor
Type of Venting:
Vent Free
Media Style:
Traditional Log Set
Type of Grate:
Standard
Fuel Type:
Liquid Propane (LP)
Allowable Log Set Sizes (in.):
18"
Allowable Log Sets:
Wild Timber; Rugged Stacked
Certified Usage:
Mobile Home Approved

Performance

BTUs (Max.):
30000
Ignition Type:
Millivolt (Remote Ready)
Remote:
Variable Flame Remote Included

Gas Requirements

Gas Connection Size (in.):
1/2"
Manifold Pressure (in.):
7.9" w.c.
Inlet Gas Pressure (Min.):
11.0" w.c.
Inlet Gas Pressure (Max.):
14.0" w.c.

Minimum Firebox Requirements

Requirements for 18" Logs

Req. Min. Front Width (in.):
28"
Req. Min. Rear Width (in.):
20"
Req. Min. Height (in.):
20"
Req. Min. Depth (in.):
14"
California residents see Prop 65 WARNINGS

Warning WARNING!

Warning: Cancer and Reproductive Harm - www.p65warnings.ca.gov

Product Warranty

Burner Warranty - Repair or replacement for one year from the date of installation. Warranty is non-transferable and extends to the original owner only. The Product must be purchased through a listed supplier of IHP and proof of purchase must be provided.
